Hitachi HUS Service Manual
Hitachi HUS Service Manual
HUS 110 (CBXSS,CBXSL) - Drive Boxes (DBS,DBL)
HUS 130 (CBSS,CBSL) - Drive Boxes (DBS,DBL,DBX,DBW)
HUS 150 (CBL,CBLD) - Drive Boxes (DBS/DBSD,DBL/DBLD,DBF,DBX,DBW)
| Type | IP | Username/Password |
|---|---|---|
| Management | 192.168.0.16-17/255.255.255.0 | system/manager, root/storage |
| Maintenance | 10.0.0.16-17/255.255.255.0 | system/manager, root/storage |
Press the Ctrl+Shift+E keys at the same time to switch Hitachi Storage Navigator Modular 2 to Maintenance Mode.
Hardware Replacement
Replacing a cache backup battery
・ Hitachi Unified Storage Hardware Service Guide.pdf?Replacing a cache backup battery
Replacing a Power Unit
・ Hitachi Unified Storage Hardware Service Guide.pdf?Replacing a Power Unit
Reference
・ Hitachi Storage Navigator Modular 2 User’s Guide.pdf
・ Hitachi Unified Storage Hardware Installation and Configuration Guide.pdf
・ Hitachi Unified Storage Hardware Service Guide.pdf
